The KX10DTP is suited for challenging environments, like in garages or conservatories. It combines PIR and microwave technologies to reduce false alarms, ensuring consistent intrusion detection despite temperature fluctuations. With pet immunity included, it's ideal for properties where pets move freely.

Key Features
  • 10m, 85° volumetric detector
  • Selectable EOL resistors
  • Digital temperature compensation

Product Features

Dual Technology Detectors are ideal for more hostile environments such as conservatories or garages. The use of a PIR and Microwave technology in one means that false alarms are reduced and the detector can maintain intruder catch performance even when the environment experiences changes in temperature. That, coupled with the KX10DTP’s pet immunity makes this detector ideal for applications where pets are free to roam the property.

Digital Temperature Compensation

When the product is used in a hot environment this technology digitally adjusts the detector’s sensitivity allowing it to maintain its range even when the background room temperature is almost equal to the external body temperature of 32ºC (internal body temperature = 37ºC).

Dual Technology Detection

Low noise dual element pyroelectric sensor and Microwave Doppler Sensor combine together to ensure the stability and reliability required for more hostile installations.

Blue Wave Technology (BWT)

This technology further enhances the detector’s immunity to infra-red noise in the environment. BWT comprises of 2 key components: 1). The new 3D optics system enables perfect focusing of the infra-red signal onto the pyro-electric sensor. This allows BWT to clearly identify the positive and negative signal edges. 2). Powerful software embedded into a microprocessor is used to process the received information from the pyro-electric sensor. The result of this combination is lower infra-red signal noise amplification and therefore better immunity.

Pet Immune / 10m volumetric detector

The detectors intelligent PI (Pet Immune) technology analyses the difference between an intruder and a pet signal, with immunity up to 24kg and 10m coverage range.

Selectable EOL resistors

The detectors incorporates selectable alarm resistor values of 6K8, 5K6, 4K7 &1K & tamper values of 5K6, 4K7, 2K2 and 1K catering for most control panels on the market.

Auto Sensitivity Feature

Depending on the environment condition, the detector will automatically adjust the sensitivity.

Tamper proof brackets

Supplied with both wall & ceiling mount brackets which provides access for up to two 8 core cables (Tamper kit optional).

ABS plastics

3mm polished finish, reduces electrostatic interference on the PIR sensor.

Sealed optics

Protects from possible infestation from insects, shields air movement in front of the pyro-electric sensor and protects against adverse reflections from inside the detector housing.

The same housing is used for all of the KX security detectors so you can mix and match the perfect detector for the room and they will still look uniformed through out your home.

Detectors technical characteristics

Blue Wave technology


Automatic sensitivity


Digital temperature compensation


DEOL resistor on board


Tamper protection

Front and Rear

Separate LED indication

Microwave, PIR, Alarm

3 microwave frequencies to avoid interference


Detectors technical characteristics

Maximum range


Volumetric coverage


Dual technology


Animal immunity


Detection speed

0.3- 3.0m/s

Coverage angle

85 degree

Detection zones


Detection planes


Anticloaking technology


White light filter

6500 lux


Ultraviolet light filter


3 dimensional


Sealed optics

Detection method

Low noise dual element pyroelectric sensor and Microwave Doppler Sensor


Wall mounted

Bracket included

Ceiling mounted

Bracket included

Optimum coverage height


Certified mounting height

1.8 - 2.4m

Environmental and operating features

Storage temperature

-40C to 80C

Certified operating temperature

-10C to 40C

Nominal operating temperature

-30C to 60C

Physical dimensions (H x W x D)

117 x 69 x 50mm



Electrical & battery

Operating voltage

9-16V DC 13.8V DC typical

Quiescent current consumption

24mA @ 12V (Min), 30mA @ 12V (Max)

Contact Resistance

<10 ohms

Relay outputs

50mA 60 VDC, 42 VAC (RMS)

Tamper switch

12V 50mA

Certifications and warranty

Security Grade

Grade 2

Environmental class


EN Certificate

EN50131-2-4:2008, EN50131-1:2006+A1:2009, PD6662:2017

Electrical conformity



5 years

Product Codes & Options

KX10DTP2 10.525GHz
SAP: 361300080
KX10DTP3 10.587GHz
SAP: 361301084
