Enforcer 64

Product Features
  • Enforcer all-in-one two-way wireless control panel

  • Maximum total zones 66
    - 32 wireless zones expandable to 64
    - 2 wired zones expandable to 34

  • 3 programmable wired outputs expandable to 38

  • 75 user codes, 32 wireless keyfobs with individual user ID

  • Built-in proximity reader (set/unset with tag)

  • 4 level sets or 4 independent areas

  • Wide range of two-way wireless peripherals available

  • Customisable push notifications

  • Complies with EN50131-1
    Security Grade 2, Environmental Class II

Control your home security from anywhere

Using the Hik-Connect App linked to the Cloud, customers can control their security system from anywhere. Arming or disarming, getting system status and receiving notifications from any event.

Superior security

Rest assured that your system is as secure as wired alternatives, with credit-card style encryption of wireless signals, fault reporting and long battery life of up to two years.

Highly secure connection

The Hik-Connect App and Cloud communications are fully encrypted to the highest standard and no sensitive user data is stored on the Cloud.

Easy to arm & disarm

Arm your system in a variety of ways with your smart device, codes, proximity tags or wireless key fobs.

One-push-to-learn

The one-push-to-learn feature in all Enforcer wireless devices means that learning devices onto the system can be done in seconds.

128-bit wireless protocol encryption

Pyronix two-way wireless protocol has been developed to protect the communications between all wireless system components with a very high security level. This ensures effective anti-code grabbing and multiple attempts at message delivery. It also provides a very high level of protection over the wireless bus, ensuring peace of mind.

Quicker installation with Signal Strength Indicators

Signal Strength Indicators (SSI) in all wireless devices means that you can position devices without the need to refer back to the panel.

Preserve battery power

Instant two-way device control enables immediate wake-up and sleep of devices; preserving battery power, while maintaining a highly secure system.

Easy to program and install

Fully menu driven programming with YES/NO questions allows for quick and simple installing; saving you time and money.

No wires, no fuss

As the system can be fully wireless, there’s no need to run wiring which means fast, efficient installations with minimum mess.

A full range of peripherals

Including safety and security sensors and detectors, the Enforcer range has the products to cover the job.

Android & Apple compatible

The Hik-Connect App is available in two versions: Android™ from the Google Play Store and iOS™ from the Apple App store.

Dual frequency

Advanced jamming detection with frequency hopping technology is used to prevent accidental or malicious attempts to disrupt the system.

EN50131-1:2006+A1:2009 | EN50131-3:2009 | EN50131-6:2008 | EN50131-5-3:2005+A1:2008 | PD6662:2010



Control panel technical characteristics

Two-way wireless technology

Yes

Independent areas

4

Part sets

4

Tamper protection

Front and rear

User codes and prox tags

80

Signalling protocols

Contact ID IP, Contact ID, SIA IP, SIA3, Fast Format IP, Fast Format and SMS

System logs

750

Enforcer two-way wireless technology

Signal Strength Indicators (SSI)

Yes

Instant two way device control (ITDC)

Yes

Pyronix high security two way wireless data encryption protocol (TDE)

Yes

Pyronix intelligent jamming detection

Yes

Programmable wireless supervision time

Yes

868MHz transceiver FM technology

Yes

Tranmission method

Fully encrypted rolling code

Transmission range

1.6km in open space

Inputs & outputs

Input type

Wireless and wired

Two-way wireless inputs

32 expandable to 64

Onboard wired inputs

2

Total inputs

66

Outputs on board

2

Output modules

1

Maximum outputs

38

Two-way wireless keyfobs

32

Two-way wireless sirens

2

Wired keypads

3

Readers and entry control

3

Communications and modems

Modem type (included)

None included

GPRS modem (optional)

Yes

LAN modem (optional)

Yes

WiFi modem (optional)

Yes

Supports Cloud & Hik-Connect App

Yes

Environmental and operating features

Storage temperature

-20C to +60C

Certified operating temperature

-10C to +40C

Nominal operating temperature

-10C to +40C

Physical dimensions (H x W x D)

160 x 220 x 60mm

Weight

1025g

Electrical & battery

Battery type

NiMH 8 cell 2200mAh rechargeable battery

Battery voltage

12.71V (with no mains and battery fully charged)

Low battery threshold

8.9V

Mains supply

230VAC -15/+10%

Operating voltage

90 - 264VAC

Supply current

222 - 75mA

Resistance (wired inputs)

Normal

3k7 or 8k3

Intruder

8k4 to 10k2

Tamper

<3k7 or >23k

Certifications and warranty

Security Grade

Grade 2

Environmental class

II

EN Certificate

EN50131-1:2006+A1:2009 | EN50131-3:2009 | EN50131-6:2008 | EN50131-5-3:2005+A1:2008 | PD6662:2010

Certification type

IMQ

Certificate number

CA12.01328

Electrical conformity

CE

Warranty

2 years

Product Codes & Options

Enforcer 64 kit (International English) w/o modem
ENF-APP-KIT-AM
SAP: 361300112
Enforcer 64 kit (International English) GPRS modem
ENF-APP-KITG-AM
SAP: 361300023
Enforcer 64 kit (Spanish) w/o modem
ENF-APP-KIT-ES
SAP: 361301706
Enforcer 64 kit (Spanish) GPRS modem
ENF-APP-KITG-ES
SAP: 361300021
Enforcer 64 kit (French) GPRS modem
ENFKIT1APP-GPRS/FR
SAP: 361301246
Enforcer 64 kit (Italian) w/o modem
ENF-APP-KIT-IT
SAP: 361300024
Enforcer 64 kit (Italian) GPRS modem
ENF-APP-KITGDT-IT
SAP: 361300161
Enforcer 64 kit (Russian) GPRS modem
ENFAPP-GPRS/RU
SAP: 361301251
